Description
Product details
1. Domestic and Community Water Supply 2. Water Supplies for High Rise Building 3. Gardening and Small Farm Irrigation 4. Farming 5. Ground Water Supply to Water Works MATERIAL OF CONSTRUCTION :- 1. Motor Housing - Stainless Steel 2. Motor Shaft - Stainless Steel 3. Motor Bearing - Ball Bearing 4. Finish Rotor - Copper 5. Motor Base & Adaptor - Cast Iron 6. Pump Shaft - Stainless Steel 7. Pump Stage Casing - Cast Iron 8. Impeller - Noryl 9. Diffuser - Noryl 10. Outlet (NRV) - Cast Iron 11. Suction Housing - Cast Iron 12. Pump Bushes - NBR / LTB APPLICATIONS :- 1. Domestic and Community Water Supply 2. Water Supplies for High Rise Building 3. Gardening and Small Farm Irrigation 4. Farming 5. Ground Water Supply to Water Works SPECIFICATIONS :- 1. Head: Up to 325 metres 2. Discharge: 480 LPM 3. Power Ratings: 2.2 kW to 15 kW (3.0 HP to 20 HP) 4. Voltage Range: 200 to 440 volts (three phase) 5. Insulation: F Class 6. Protection: IP 68
